Ultrasonic Level Meter

Efficient Liquid Level Monitoring

Our Ultrasonic Tank Level Monitoring Meter offers advanced features for precise liquid level measurement. It supports GPRS and Wi-Fi connectivity, allowing for easy backup and restoration of settings. This sensor measures material levels, liquid levels, volume, and weight, and includes options for analog output adjustment, digital filtering, and echo recognition. It also features RS485, RS232, and relay connections, with an explosion-proof model available.

The meter has a measurement range of 5 to 30 meters, a beam angle of ≤10°, and a high resolution of 1mm. It operates within a frequency range of 20 KHz to 2000 KHz and offers an accuracy of ±0.3% F.S. Display options include LED, LCD, or OLED. With its versatile output and communication capabilities, the BQ-ULM is a reliable choice for monitoring tank and water levels.

Safety Ultrasonic level meter has backup and recovery parameter set. IP65 and customized for IP68; All input and output lines are lightning protected and against short circuits.
Stable and Reliable Top quality components and design provide excellent stability and reliability.
Multi-Function - Measures Air or Liquid Levels
This ultrasonic level meter can measure airspace or liquid levels.
High Precision Level resolution is 1 mm against various kinds of interference waves.
Low Failure Rate, Easy to Install and Maintain
The instrument is not in direct contract with the liquid, which results in a lower failure rate. Offers a variety of installation options and manual calibration.

Ordering Notes:
All Inline Water Quality Meters and Sensors ship direct from the factory, and have a 10 day lead time for shipping.


Range 5, 8, 10, 12, 15m
Blind Zone <0.3-0.5m (different for range)
Display resolution 1mm
Frequency 20~350KHz
Power 12-24VDC; consumption:<1.5W
Output 4~20mA RL>600Ω(standard),1~5V\1~10V
Communication RS485
Relay 2 relays (AC: 5A 250V DC: 10A 24V)
Material ABS
Dimension Φ92mm×198mm×M60
Protection IP65 (others optional)
Connection Electrical interface: M20X1.5, Installation: M60X2 or ¢61MM
